SPECIFICATIONS:
Frame: Trek 100 Series Alpha Aluminium, tapered head tube, internal routing, fender mounts, DuoTrap S compatible, flat mount disc, 142x12 thru-axle
Fork: Trek Domane AL carbon, tapered alloy steerer, internal brake routing, mudguard mounts, flat mount disc, 12x100mm thru-axle
Headset: FSA Integrated, sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Bottom Bracket: Shimano UN26, 68mm, threaded cartridge, 110mm spindle
Stem: Bontrager Elite, 31.8mm, Blendr compatible, 7-degree, 70mm length (size 44), 80mm length ( size 49), 90mm length (size 52 & 54), 100mm length (56 & 58), 110mm length (size 61)
Handlebar: Bontrager Comp VR-C, alloy 31.8mm, 100mm reach, 124mm drop, 38cm width (size 44 & 49), 40cm width (size 52), 42cm width (size 54 & 56), 44cm width (size 58 & 61)
Bar Tape: Bontrager Supertack Perf
Front Brake: Tektro C550 mechanical disc brake, dual-piston, flat mount, 160mm rotor
Rear Brake: Tektro C550 mechanical disc brake, dual-piston, flat mount, 160mm rotor
Brake Levers: Shimano Claris R2000
Front Derailleur: Shimano Claris R2000, 31.8mm clamp
Rear Derailleur: Shimano Claris R2000, long cage, 34T maximum cog, 8-speed
Shift Levers: Shimano Claris R2000, 8-speed
Chain: Shimano Sora HG71, 8-speed
Cassette: Shimano HG31, 11-32, 8-speed
Crankset: Shimano RS200, 50/34 (compact), 165mm length (size 44), 170mm length (size 49, 52 & 54), 175mm length (size 56, 58 & 61)
Front Wheel: Formula RX-512 alloy, 6-bolt, 100x12mm thru-axle hub / Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21mm width, Presta valve rim
Rear Wheel: Formula RX-142 alloy, 6-bolt, Shimano 11-speed freehub, 142x12mm thru-axle / Bontrager Affinity Disc, Tubeless Ready, 24-hole, 21mm width, Presta valve rim
Front Tyre: Bontrager R1 Hard-Case Lite, wire bead, 60 TPI, 700x32c, clincher
Rear Tyre: Bontrager R1 Hard-Case Lite, wire bead, 60 TPI, 700x32c, clincher
Saddle: Bontrager P3 Verse, steel rails, 155mm width (size 44, 49 & 52), 145mm width (size 54, 56, 58 & 61)
Seatpost: Bontrager alloy, 27.2mm, 8mm offset, 250mm length (size 44 & 49), 330mm length (size 52, 54, 56, 58 & 61)
Pedals: Available to be purchased separately
Manufacturer Claimed Weight: 10.55 kg / 23.26 lbs (size 56)
Weight Limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg / 275 lb
Max Tyre Size: 35c without fenders, 32c with fenders
